| Brand Name: | YEOAN |
| Model Number: | TM-75 |
| MOQ: | 30 |
| Payment Terms: | L/C, T/T |
| Display Type | LCD |
|---|---|
| Screen Size | 75 inches |
| Visible Area | 1652*930 mm |
| Brightness | 350 cd/m² |
| Viewing Angle | 178° |
| Response Time | 6.5 ms |
| Contrast Ratio | 6000:1 |
| Resolution | 3840*2160 (pixels) |
| Mounting Type | Standing or wall install |
| Pixel Pitch | 0.42*0.42 mm |
| Operating System | Android or Windows |
The multimedia teaching all-in-one machine combines infrared touch technology, intelligent office teaching software, multimedia network communication technology, and high-definition flat-panel display technology into a single multifunctional interactive teaching device. This advanced system integrates the functionality of projectors, projection screens, electronic whiteboards, computers (optional), TVs, and touch screens, transforming traditional display terminals into full-featured human-computer interaction devices.
With this product, users can write, annotate, draw, perform multimedia entertainment, and computer operations. Simply turn on the device to conduct interactive classes with ease.
Features a professional industrial LCD display with extended lifespan and high stability, specifically designed for continuous operation in educational environments.
Full-screen HD display with 1080P resolution, 6000:1 contrast ratio, 16.77 million colors, and 16:9 cinema widescreen format ensures vibrant, clear visuals in any lighting condition.
Includes comprehensive teaching software with 178-degree viewing angle capability using S-PVA&S-IPS technology for all-around visibility.
Modular computer design with OPS/pull-out PC settings for convenient maintenance and upgrades.
Multiple input interfaces including composite video, component video, VGA, DVI, HDMI, and more for maximum compatibility with various devices.
| Display Parameters | |
|---|---|
| Panel Size | 75" |
| Resolution | 3840*2160 (pixels) |
| Pixel Pitch | 0.42*0.42 mm |
| Brightness | 350cd/m² (typ.) |
| Contrast | 6000:1 (typ.) |
| Response Time | 8.5ms (typ.) |
| Viewing Area (H*V) | 1652*930 mm |
| Viewing Angle (H*V) | 178° / 178° |
| Service Life | 50,000 hrs (typ.) |
| Android Function Parameters | |
| Operating System | Android 12 |
| Processor | V100 Octa-core Cortex-A55*8 Frequency 1.5GHz |
| Memory | 4GB RAM + 32GB Storage |
| Network | 100M Ethernet/WiFi-2.4G/5G Hot Spots |
| Physical Specifications | |
| Dimensions (W*H*D) | 1710*1022.6*89.6 mm |
| Net Weight | 46 Kg |
| Gross Weight | 56KG±1 Kg |
Optional OPS Computer: Configurable with I3/I5/I7 processors, 4G/8G/16G memory, and 128G/256G/512G hard disk options.
