Large Venue led 4k Laser Projector Short Throw Business HD WUXGA 50Inch Screen 7300lm

Brand Name:	Yeoan
Model Number:	YA706
MOQ:	5
Payment Terms:	L/C, T/T, Western Union

Detail Information

Product Description

Detail Information

Document:

Product Brochure PDF

Display Technology:

3LCD

Projection Light Source:

Laser

Brightness:

7300lm

Standard Resolution:

WUXGA (1920 X 1200)

Projection Ratio:

0.68~0.82：1

Zoom Ratio:

1.21X Zoom

Aspect Ratio:

Native:16:10 Compatible: 4:3/16:9

Focus Mode:

Manual

Keystone Correction:

V: ±15° H：±15°

Lens Shift:

V:＋50%～0%、 H：±23%

Packaging Details:

Packaging Box Dimensions (WxDxH mm): 510（W)*498(D)*260(H)

Highlight:

7300lm 4k laser projector short throw

Large Venue 4k laser projector short throw

50Inch short throw led projector

Product Description

Large Venue LED 4K Laser Projector - Short Throw Business HD WUXGA with 50-300 Inch Screen (7300lm)

Key Features

High Brightness: 7300 lumens for clear visibility in large venues
WUXGA Resolution: 1920 x 1200 native resolution with 4K compatibility
Laser Light Source: 30,000 hours of ultra-long life
Short Throw Ratio: 0.68~0.82:1 for flexible installation
Dynamic Contrast: 5,000,000:1 ratio for vivid images
Versatile Installation: 360° projection and lens shift capabilities
Low Maintenance: IP6X dust-resistant optical engine

Technical Specifications

Display Technology	3LCD
Light Source	Laser
Brightness	7300lm (MKT), 6600lm (TYP), 5840lm (MIN)
Resolution	WUXGA (1920 x 1200)
Projection Ratio	0.68~0.82:1
Zoom Ratio	1.21X
Aspect Ratio	Native 16:10 (Compatible 4:3/16:9)
Contrast Ratio	5,000,000:1
Light Source Life	20,000-30,000 hours

Advanced Features

This high-performance laser projector combines professional-grade brightness with exceptional image quality. The short throw design allows for large screen sizes (50-300 inches) from short distances, while manual lens shift (vertical +50% to 0%, horizontal ±23%) provides flexible installation options.

The projector features hexagonal correction, multi-point correction, and edge blending capabilities for perfect image alignment. With 360° projection capability, it can be installed in virtually any orientation to suit your venue requirements.

Professional Applications

Ideal for demanding environments including:

Large venues and auditoriums
Educational institutions and lecture halls
Corporate meeting rooms and boardrooms
Museums and cultural centers
Places of worship
Digital signage installations
Immersive experiences

Connectivity & Control

Comprehensive I/O ports include HDMI 2.1, VGA, USB, RJ45, and RS232 control. The projector supports LAN control protocols including Crestron RoomView, AMX Discovery, and PJ Link. Optional wireless display module allows for smartphone and PC connectivity.

Environmental Specifications

Operating Temperature	0°C to 50°C (0-1700m altitude)
Operating Humidity	20-85%
Noise Level	39dB (Normal), 31dB (ECO1), 29dB (ECO2)
Power Consumption	425W (Max), <0.5W (Standby)
Dimensions	405 × 425 × 137 mm (8.1kg)
