| Brand Name: | Yeoan |
| Model Number: | YA-526U |
| MOQ: | 5 |
| Payment Terms: | L/C, T/T, Western Union |
| Display Technology | 3LCD |
|---|---|
| Light Source | Laser |
| Brightness | 5200 lumens (marketing), 4680 lumens (typical) |
| Resolution | WUXGA (1920×1200) |
| Contrast Ratio | 5,000,000:1 (dynamic), 400:1 (native) |
| Projection Size | 30-300 inches |
| Throw Ratio | 1.37~1.65:1 |
| Aspect Ratio | Native 16:10, Compatible 4:3/16:9 |
| Light Source Life | 20,000 hours (Normal), 30,000 hours (ECO modes) |
HDR10 Support: Full 10-bit color output delivers an extraordinary range of color and detail in both bright and dark scenes.
100% Balanced Color Brightness: 2,200 lumens of equal color and white brightness ensures vibrant, rich colors.
Flexible Installation: 360° projection capability and multiple mounting options.
Network Control: Supports PJ Link, Crestron RoomView, and AMX Discovery for integration with control systems.
| Inputs | VGA (x1), HDMI (x2), Video (x1), Audio (3.5mm and RCA), USB-A (x1), USB-B (x1), RJ45 (x1) |
|---|---|
| Outputs | VGA (x1), Audio (3.5mm) |
| Control | RS232 (x1), RJ45 (x1) |
Ideal for home theaters, classrooms, offices, meeting rooms, hotels, hospitals, schools, churches, and industrial environments.
| Dimensions (W×D×H) | 390 × 294 × 128 mm |
|---|---|
| Weight | 5 kg (net), 6.5 kg (gross) |
| Operating Temperature | 0 to 40°C |
| Noise Level | 37 dB (Normal), 30 dB (ECO1), 28 dB (ECO2) |
