| Brand Name: | YEOAN |
| Model Number: | TA-156 |
| MOQ: | 100 |
| Payment Terms: | L/C, T/T |
| Attribute | Value |
|---|---|
| Mounting Type | Wall mounted |
| Display Type | LCD |
| Screen Size | 15.6 inch |
| Power Supply | AC 100-240V, 50/60Hz |
| Viewing Angle | 178° |
| Response Time | 30 ms |
| Contrast Ratio | 3000:1 |
| Resolution | 1920x1080 |
| Brightness | 250 cd/m² |
| Touch Screen | Yes |
| Connectivity | HDMI, VGA, USB |
| Operating System | Android or Windows |
| Language Menu | English, Chinese and other languages |
| Metal Shape | Can be customized |
| Frame Colour | Can be customized |
| Starting Up | Auto-loop playback |
| Size | 15.6" | 18.5" |
|---|---|---|
| Display Parameters | ||
| Panel size | 15.6" | 18.5" |
| Resolution | 1920*1080(pixels) | 1920*1080(pixels) |
| Pixel pitch | 0.18*0.18 mm | 0.21*0.21 mm |
| Brightness | 250cd/m² (typ.) | 250cd/m² (typ.) |
| Contrast | 3000:1 (typ.) | 1200:1 (typ.) |
| Color | 16.7M (8bit) | 16.7M (8bit) |
| Response time | 30ms (typ.) | 14ms (typ.) |
| Viewing area (H*V) | 344.16*193.59 mm | 409.8*230.4 mm |
| Angle (H*V) | 178° / 178° | 178° / 178° |
| Service life | 30,000 hrs (typ.) | 30,000 hrs (typ.) |
| Mainboard Parameters (Optional) | ||
| Mainboard | 352 motherboard (2K solution) | RK3566 motherboard (2K solution) |
| Operating System | Android 9.0 | Android 11 |
| Chip | Hi3751 Quad Core cortex A53 Frequency 1.0GHz | RK3566 Quad Core cortex A55 Frequency 1.8GHz |
| Memory | 1G | 2G |
| Storage | 8G | 16G |
| Network | 100M Ethernet/WiFi-2.4G | 100M Ethernet/WiFi-2.4G |
| External Connection Port | ||
| USB2.0 | *1 | *1 (support 1 road USB 3.0) |
| USB2.0(OTG) | *1 | *1 |
| HDMI interface | *1 (support HDMI enter) | *1 (support HDMI Output) |
| RJ45 | *1 | *1 |
| WIFI 2.4G antenna | *1 | *1 |
| Power Supply | ||
| Speaker power | 5W*2 | 5W*2 |
| Standby power | ≤0.5W | ≤0.5W |
| Power supply for the whole machine | AC110V-220V, 50-60 Hz | AC110V-220V, 50-60 Hz |
| Machine power | ≤30W | ≤40W |
| Work Environment | ||
| Operating temperature | 0℃~40℃ | 0℃~40℃ |
| Operating humidity | 20%~85% (No condensation) | 20%~85% (No condensation) |
| Storage temperature | -10℃～60℃ | -10℃～60℃ |
| Storage humidity | 10%~60% (No condensation) | 10%~60% (No condensation) |
| Material | ||
| Housing Material | Aluminum frame + tempered glass + metal back cover | Aluminum frame + tempered glass + metal back cover |
| Shell color | Silver + black frame + black back cover | Silver + black frame + black back cover |
| Dimensions | ||
| Bare metal size (W*H*D) | 376.4*236.4*52.2 mm | 443.4*267.4*56.2 mm |
| External dimensions of packaging (W*H*D) | 450*310*110mm | 520*345*110 mm |
| VESA hole | 100*100mm, 4*M4 screw | 100*100mm, 4*M4 screw |
| Weight | ||
| Net weight | 3.5KG | 4KG |
| Gross Weight | 4KG | 4.5KG |
| Appendix | ||
| Remote Control | *1 | *1 |
| Power cord | *1 | *1 |
| Warranty card | *1 | *1 |
| Certificate | *1 | *1 |
| Wall Mount | *1 | *1 |
