| Brand Name: | YEOAN |
| Model Number: | YLD |
| MOQ: | 50 |
| Payment Terms: | L/C, T/T |
| Attribute | Value |
|---|---|
| Size | Various size |
| Best View Distance | 4-47m |
| Warranty | 2 years |
| Screen Material | LED display board |
| Operating Life | >460000 hours |
| Life Span | 100000 hours |
| LEDs | SMD 3in1 |
| Operation Temperature | -20℃~70℃ |
| Usage | Outdoor and indoor |
| Color Processing | 16.7 million |
| Viewing Angle | Wide |
| Model No. | LT-Poster1.5 | LT-Poster1.8 | LT-Poster1.5 | LT-Poster1.8 | LT-Poster2.0 | LT-Poster2.5 |
|---|---|---|---|---|---|---|
| Pixel density (mm) | 1.5 | 1.8 | 1.5 | 1.8 | 2 | 2.5 |
| LED type | SMD | SMD | SMD | SMD | SMD | SMD |
| Display size (W×H)(mm) | 600×1687.5 | 600×2025 | 640×1920 | 640×1920 | 640×1920 | 640×1920 |
| Display resolution (W×H)(pixel) | 384×1080 | 320×1080 | 416×1248 | 344×1032 | 320×960 | 256×768 |
| Weight (kg) | 57/34 | 61/38 | 71/42 | |||
| Housing material | AL. | |||||
| Viewing angle (H/V) | 160°/160° | |||||
| Refresh frequency (Hz) | 3840 | |||||
| Contrast ratio | 8000:1 | |||||
| Brightness (nits) | 600 | 500 | ||||
| Voltage | AC100~240 | |||||
| Average power consumption (W/m²) | 120 | 125 | 120 | 125 | 115 | 105 |
| Max. power consumption (W/m²) | 480 | 500 | 480 | 500 | 460 | 420 |
| Operating system | Android | |||||
| Video interface | HDMI×2 (1 in 1 out), USB 3.0×1 | |||||
| Control interface | RJ45, WIFI, local AP network, 4G network (optional) | |||||
| Maintenance way | Front (screen)/rear (control case) | |||||
| IP class | Front IP30/rear IP60 | |||||
